| 搅拌点位数目 |
1 |
| 最大搅拌量 (H2O) |
20 l |
| 电机输出功率 |
9 W |
| Direction of rotation |
right / left |
| Speed display set-value |
LCD |
| Speed display actual-value |
LCD |
| 转速控制 |
Turning knob |
| 速度范围 |
50 - 1500 rpm |
| 转速设置精度 |
10 rpm |
| 最小搅拌子长度 |
30 mm |
| 搅拌子最大长度 |
80 mm |
| 加热盘自热（室温:22°C/保持:1小时） |
8 +K |
| 加热输出功率 |
600 W |
| Temperature display set-value |
LCD |
| Temperature display actual-value |
LCD |
| Temperature unit |
°C / °F |
| 加热温度范围 |
Room temp. + device self heating - 310 °C |
| 加热温度控制 |
Turning knob |
| Temperature setting range min. |
0 °C |
| Temperature setting range max. |
310 °C |
| Temperature setting resolution of heating plate |
1 K |
| 外接温度传感器接口 |
PT1000, ETS-D5, ETS-D6 |
| Heating rate medium |
7 K/min |
| Temperature setting resolution of medium |
1 K |
| 可调安全温度回路最小值 |
50 °C |
| 可调安全温度回路最大值 |
370 °C |
| 工作盘材质 |
铝合金 |
| 工作盘外形尺寸 |
? 135 mm |
| Automatic reverse rotation |
是 |
| Intermittend mode |
是 |
| 粘度变化趋势测量 |
是 |
| 搅拌子跳子检测 |
不 |
| 计时器 |
是 |
| pH measurement |
不 |
| Graph function |
不 |
| Programs |
不 |
| Sensor in medium detection (Error 5) |
是 |
| 称重功能 |
不 |
| Set-up plate illuminated |
不 |
| Speed deviation (no load,nominal voltage, at 1500rpm + 25 °C) |
2 ±% |
| Heating rate (1l H2O in H1500) |
7 K/min |
| Heat control accuracy of heating plate (at 100°C) |
5 ±K |
| Heat control accuracy with ext. PT1000 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C) |
0.5 ±K |
| Heat control accuracy with ETS-D5 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C) |
0.5 ±K |
| Heat control accuracy with ETS-D6 (500ml H2O in 600ml beaker,40mm stirring bar,600rpm,50°C) |
0.2 ±K |
| 外形尺寸 |
160 x 85 x 270 mm |
| 重量 |
2.4 kg |
| 允许环境温度 |
5 - 40 °C |
| 允许相对湿度 |
80 % |
| DIN EN 60529 保护方式 |
IP 42 |
| RS 232接口 |
是 |
| USB接口 |
是 |
| 模拟输出 |
不 |
| 电压 |
220 - 230 / 115 / 100 V |
| 频率 |
50/60 Hz |
| 仪器输入功率 |
650 W |
| 仪器输入功率 Standby |
1.6 W |
